Deployment

The Deployment module manages the automated deployment of approved metadata changes to target applications. It provides centralized control over when and how metadata is deployed, with comprehensive monitoring, scheduling, and multi-environment support.

Deployment module showing Manager, Monitor, and Schedule tabs

Overview

The Deployment module consists of three integrated components:

Deployment Manager - Create and configure deployment definitions
Deployment Monitor - Track deployment execution and status
Deployment Schedule - View and manage scheduled deployments

Key capabilities include: - Direct deployment to target applications - File-based deployment for manual processing - Interface table deployment for integrations - Multi-environment cascade deployments - Pre and post-deployment scripting - Comprehensive email notifications

Quick Links

⚙️ Manager

Configure deployment types, scripts, and notifications

Manage Deployments →

📊 Monitor

Track deployment status and view logs

Monitor Status →

📅 Schedule

Configure automated deployment timing

Set Schedule →

🔄 Redeployment

Handle failed deployments and retries

Learn More →

Deployment Manager

Deployment Manager creates and manages deployment configurations that determine what, when, and how metadata is deployed.

Deployment Manager showing configured deployments

Deployment Components

Component	Description	Options
Name	Deployment identifier	User-defined
Description	Deployment purpose	Optional text
Type	Deployment scope	Application, Workflow, Request
Pre-Deployment Scripts	Scripts run before deployment	Logic Builder scripts
Post-Deployment Scripts	Scripts run after deployment	Logic Builder scripts
Email Templates	Success/error notifications	From Email Templates
Attachments	Files to include	Deployment files, logs
Environment	Target environment	Multi-environment only

Deployment Types

Application Deployment

Deploys all approved requests for an entire application: - Processes all pending requests - Batches changes together - Most efficient for regular updates - Typically scheduled

Workflow Deployment

Deploys approved requests from specific workflows: - Workflow-specific processing - Useful for different SLAs - Segregates by business process - Can have different schedules

Request Deployment

Deploys individual or grouped requests: - Selective deployment - Emergency changes - Failed request redeployment - Manual control

Creating Deployments

Add Deployment configuration dialog

Navigate to Deployment → Manager
Click the + icon
Configure deployment:

Field	Required	Description
Deployment Name	Yes	Unique identifier
Description	No	Deployment purpose
Deployment Type	Yes	Application/Workflow/Request
Pre-Deployment Script	No	Logic Builder script to run before
Post-Deployment Script	No	Logic Builder script to run after
Email on Success	No	Success notification template
Email on Error	No	Error notification template
Attach Deployment Files	No	Include metadata files
Attach Log Files	No	Include execution logs
Enabled	Yes	Activate deployment
Environment	Conditional	For multi-environment setups

Click Save

Example: Production Application Deployment

Name: PROD_HFM_Daily
Description: Daily HFM production deployment
Type: Application
Pre-Deployment Script: BACKUP_HFM_METADATA
Post-Deployment Script: REFRESH_ESSBASE_CALC
Email on Success: DEP_Success_Summary
Email on Error: DEP_Failed_Alert
Attach Deployment Files: ✓
Attach Log Files: ✓
Enabled: ✓

Editing Deployments

Deployment Properties edit dialog

Right-click on deployment row
Select Edit Properties
Modify configuration
Click Save

Request-Based Deployment

For selective or failed request redeployment:

Create Request-type deployment
Click Save
Click "Requests" link in grid
Select Ready for Deployment radio button
Choose specific requests
Click Save
Schedule deployment

Request selection for targeted deployment

Scheduling Deployments

Configure when deployments execute automatically.

Schedule Deployment configuration options

Schedule Types

Auto (Immediate)

Deploys as soon as requests are ready: - Real-time processing - No delay - Best for urgent changes - Continuous monitoring

Daily

Runs at specified time each day:

Daily schedule configuration

Frequency: Daily
Time: 11:00 PM
Days: All days

Weekly

Runs on selected days of the week:

Weekly schedule with day selection

Frequency: Weekly
Days: Monday, Wednesday, Friday
Time: 10:00 PM

Monthly

Runs on specific day each month:

Monthly schedule configuration

Frequency: Monthly
Day: Last day of month
Time: 11:30 PM

One Time

Single execution at specified datetime:

One-time schedule configuration

Frequency: One Time
Date: 12/31/2024
Time: 11:59 PM

Hourly

Runs every specified number of hours:

Hourly schedule interval

Frequency: Hourly
Interval: Every 4 hours
Starting: 8:00 AM

By Minutes

Runs at minute intervals:

Minute-based schedule

Frequency: By Minutes
Interval: Every 15 minutes

Scheduling Process

Click schedule icon (📅) for deployment
Select schedule type
Configure parameters
Click Save

Schedule Best Practices

Production: Daily during maintenance window
UAT: Hourly or by minutes for testing
Development: Auto for immediate feedback

Deployment Monitor

Monitor deployment execution status and access logs.

Deployment Monitor showing execution history

Monitor Grid Columns

Column	Description	Information
Deployment Id	Unique execution ID	Click for details
Name	Deployment name	From Manager tab
Description	Deployment description	User-defined
Type	Deployment type	Application/Workflow/Request
Start Time	Execution start	Timestamp
End Time	Execution completion	Timestamp
Status	Current state	Running/Completed
Log	Execution log	Click to view

Grid Controls

Filter

Filter deployments by criteria:

Deployment search and filter options

Date range
Status
Deployment name
Type

Auto Refresh

Enable automatic grid updates:

Auto refresh toggle

Updates every 60 seconds (configurable)
Shows real-time status
Useful during deployments

Deployment Status Details

Click on Deployment ID to view detailed status:

Deployment Status showing request details

Column	Description
Request ID	Request identifier
Application	Target application
Status	Deployment result
Start/End Time	Processing times
Error Message	Failure details

Status Icons

Deployment status icon legend

Icon	Status	Description
✅	Completed	Successfully deployed
⏳	Pending	Awaiting action
⚠️	Partial	Some items failed
❌	Failed	Deployment failed
🔄	Running	Currently executing

Redeployment

Handle failed or partial deployments through redeployment.

Redeployment Options

Full Deployment Retry

Redeploy all failed requests in a deployment:

Right-click on deployment row in Monitor
Select Redeploy
Failed requests return to deployment pool
Wait for next scheduled run

Individual Request Retry

Redeploy specific failed requests:

Click Deployment ID in Monitor
Right-click on failed request
Select Redeploy
Request queued for next run

Redeployment Behavior

Redeployed requests are added to the deployment pool and processed during the next scheduled execution.

Handling Partial Deployments

When deployment status shows Partial:

Identify Failed Items:
Click Deployment ID
Review failed request lines
Note error messages
Resolution Options:
Fix data issues and redeploy
Cancel failed lines
Manually close deployment
Prevention:
Add validation stages
Improve pre-deployment scripts
Test in lower environments

Multi-Environment Deployment

Deploy metadata through multiple environments in sequence.

Configuration Overview

graph LR
    A[Approved Request] --> B[Deploy to DEV]
    B --> C[Deploy to UAT]
    C --> D[Deploy to PROD]

Setup Components

Shell Applications - Logical non-production apps
Environments - Define tiers (DEV, UAT, PROD)
Deployment Order - Sequence of deployments
Environment Mapping - Link apps to environments

Example Configuration

Define Environments

Environment	Deployment Order	Description
Development	1	First deployment
UAT	2	After DEV success
Production	3	Final deployment

Create Environment-Specific Deployments

Deployment 1:
Name: DEP_Development
Environment: Development
Schedule: Auto

Deployment 2:
Name: DEP_UAT
Environment: UAT
Schedule: Daily 6:00 PM

Deployment 3:
Name: DEP_Production
Environment: Production
Schedule: Daily 11:00 PM

Deployment Scripts

Enhance deployments with Logic Builder scripts.

Pre-Deployment Scripts

Execute before metadata deployment:

// Backup current metadata
function preDeploymentBackup(context) {
    var timestamp = new Date().toISOString();
    var backupName = context.applicationName + "_" + timestamp;

    // Create backup
    backupMetadata(context.applicationId, backupName);

    // Validate target system availability
    if (!isSystemAvailable(context.targetServer)) {
        throw new Error("Target system unavailable");
    }

    return {
        status: "SUCCESS",
        backupName: backupName
    };
}

Post-Deployment Scripts

Execute after successful deployment:

// Refresh dependent systems
function postDeploymentRefresh(context) {
    // Refresh Essbase outline
    refreshEssbaseOutline(context.applicationName);

    // Clear and reload Smart View
    clearSmartViewCache();

    // Send notification to users
    notifyUsers(context.deploymentId, "Deployment completed");

    // Update audit log
    logDeployment(context);

    return { status: "SUCCESS" };
}

Deployment Schedule Tab

View all scheduled deployments in one place.

Deployment Schedule showing upcoming executions

Schedule Grid Information

Column	Description
Name	Deployment name
Description	Deployment purpose
Next Deployment Date	Next execution time
Frequency	Schedule type
Type	Deployment type

Managing Schedules

Modify: Change via Manager tab
Disable: Uncheck enabled in Manager
View History: Check Monitor tab
Upcoming: Sort by next deployment date

Best Practices

1. Deployment Strategy

Batch Similar Changes - Group related updates
Off-Peak Scheduling - Deploy during maintenance windows
Environment Progression - DEV → UAT → PROD
Backup First - Always backup before deployment
Test Scripts - Validate pre/post scripts

2. Schedule Optimization

Production - Daily at 11 PM or later
UAT - Multiple times daily
Development - Auto or frequent
Emergency - One-time deployments
Batch Size - Limit requests per deployment

3. Monitoring

Enable Auto-Refresh - During deployments
Check Logs - Review for warnings
Track Patterns - Identify recurring issues
Set Alerts - Email on failures
Archive Logs - Maintain history

4. Error Handling

Immediate Notification - Email on error
Log Attachment - Include in notifications
Redeploy Strategy - Define retry approach
Root Cause Analysis - Track failure patterns
Rollback Plans - Document procedures

Troubleshooting

Common Issues

Issue	Cause	Solution
Deployment not running	Not scheduled or disabled	Check schedule and enabled status
Stuck in Running	Timeout or system issue	Check logs, restart service
Partial deployment	Some requests failed	Review errors, redeploy failed
No requests found	Wrong type or filter	Verify deployment type configuration
Email not sent	Template not configured	Check email template assignment
Script error	Logic Builder issue	Debug script independently
Wrong environment	Mapping incorrect	Verify environment configuration

Deployment Logs

Access detailed logs:

Click log icon in Monitor grid
Review for:
Error messages
Warning indicators
Processing times
Request details

Service Management

Check deployment service:

Navigate to Administration → Services
Verify Deployment Service status
Start/stop as needed
Check service interval settings

Performance Tuning

Optimize deployment performance:

Global Settings → Application Settings:
- Maximum # of Minutes for Deployment: 180
- Deployment Service Sleep Interval: 5
- File Size Limits: Adjust as needed

Integration Points

Workflow Integration

Deploy stages in workflows: - Create deploy task - Assign to deploy stage - Configure environment - Link to deployment

Email Templates

Deployment notifications: - Success templates - Error templates - Custom variables - Table insertions

Logic Builder

Pre/post scripts: - Validation logic - Backup procedures - System integration - Custom processing

Multi-Environment

Environment configuration: - Infrastructure setup - Application mapping - Deployment order - Shell applications

Workflow Builder - Configure deploy stages
Email Templates - Deployment notifications
Logic Builder - Pre/post scripts
Infrastructure - Environment setup
Global Settings - Timeout and interval configuration
Services - Deployment service management
